Home / Products / Barbells & Attachments / Olympic Barbells
04.01 · Barbells & Attachments
Olympic Barbells
20 kg men's, 15 kg women's and technique bars. Bushing or bearing sleeves.
Overview
Olympic Barbells, factory direct
Straight Olympic bars for commercial gyms, weightlifting facilities and private-label ranges. 2200 mm men's and 2010 mm women's lengths, with 28, 28.5 or 30 mm shafts depending on use, and 50 mm rotating sleeves on bronze bushings or needle bearings. Shorter 1200, 1500 and 1800 mm bars are produced for studios and racks with limited width.
Specification
| Product code | IH-BA-OB |
|---|---|
| Material | Alloy spring steel shaft + chrome/hard chrome sleeves |
| Weight range | 15 kg / 20 kg |
| Dimensions | 2200×Ø28 mm (20 kg); 2010×Ø25 mm (15 kg) |
| Weight tolerance | ±1% typical |
| Logo method | Laser engraving / end-cap logo |
| Standard colours | Chrome/black shaft |
| OEM options | Logo, shaft coating, knurling, bearing/bushing, end cap, packaging |
Commercial terms
| MOQ | 50 pcs |
|---|---|
| OEM / private-label MOQ | 100 pcs |
| Custom Pantone MOQ | 100 pcs |
| Production lead time | 35 days |
| Sample | USD 120, freight at cost |
| FOB port | Shanghai |
| Test reports | 190,000 PSI target; load test on request |
Packing and container loading
| Packing | PE bag + tube/carton |
|---|---|
| Units per carton | 1 |
| Carton weight | NW 20 kg / GW 21 kg |
| Carton size | 222 × 8 × 8 cm |
| CBM per carton | 0.01421 |
| Container loading | 20 ft: 1,023 pcs · 40 ft: 1,238 pcs · 40 ft HQ: 1,238 pcs |
Container figures are planning estimates, not a guaranteed load. They are calculated as the lower of usable packed volume (28 / 56 / 68 m³ for 20 ft, 40 ft and 40 ft HQ) and gross payload (21.5 / 26 / 26 tonnes). Free weights are normally payload-limited, which is why a 40 ft high cube carries no more weight than a standard 40 ft. Actual loading is confirmed against your assortment and destination port before the proforma invoice is issued.
Figures marked in yellow are confirmed per model on the specification sheet supplied with your quotation. Container loading (net/gross weight, carton size, 20ft / 40ft / 40ft HC quantities) is issued with every quote.
Private label options
- Laser engraved on sleeve or shaft, custom end cap
- Colour: custom on request
- Weight marking in kg, lb or dual
- Bulk export carton, pair box or retail packaging with your artwork
- Sample with your logo before bulk production
Gallery
FAQ
Olympic Barbells: FAQ
Bushing or bearing?
Bronze bushings for general commercial use and powerlifting; needle bearings for weightlifting where fast sleeve rotation matters.
Do you make 1-inch standard bars?
Yes, on request. Our standard specification is the 50 mm Olympic sleeve.
What is the minimum order quantity?
Standard MOQ is 500 kg per SKU; private-label with a moulded logo starts at 1,000 kg per SKU, as does a custom Pantone colour. Mixed containers across dumbbells, plates, kettlebells, bars and sewn goods are accepted, and a first order is normally one 20ft container.
How long does production take?
Sampling normally takes two to three weeks after artwork approval. Bulk lead time runs 25 to 40 days depending on the line and coating, quoted per order with your proforma invoice.
Do you publish test certificates?
We publish specifications we can stand behind and we do not publish third-party certification we do not hold. Every batch is weight-checked against calibrated scales and inspected in house for coating, dimension and finish. Where a market or a tender requires independent test data, appoint your own testing or inspection agency — we will supply samples and arrange access to production. We would rather you verify than take our word for it.
Also in Barbells & Attachments
Related lines
Often specified together
Related lines
Request a quotation
Send the list. Get price, lead time and container loading in one working day.
Item list, quantities and destination port are enough to start. Logo artwork and colour references can follow once the price is agreed.
