Rubber Tri-Grip Plates
The volume commercial grip plate, from 1.25 kg. Black or colour-coded.
Overview
Rubber Tri-Grip Plates, factory direct
Moulded rubber over a cast or machined steel disc, with three grip openings. The most cost-efficient commercial plate for racks, schools and budget-conscious chains, and the plate most distributors sell by the container. Produced with a chromed or stainless steel bore insert.
Specification
| Product code | IH-WP-RTG |
|---|---|
| Material | Virgin rubber + cast iron core + steel hub |
| Weight range | 2.5/5/10/15/20/25 kg |
| Dimensions | Ø250–450 mm; thickness 20–45 mm |
| Weight tolerance | ±2% typical |
| Logo method | Embossed / molded logo |
| Standard colours | Black |
| OEM options | Custom logo, color marking, weight marking, packaging |
Commercial terms
| MOQ | 500 kg |
|---|---|
| OEM / private-label MOQ | 1000 kg |
| Custom Pantone MOQ | 1000 kg |
| Production lead time | 25 days |
| Sample | USD 40, freight at cost |
| FOB port | Shanghai |
| Test reports | Independent testing at buyer's appointment |
Packing and container loading
| Packing | 1 pc/polybag + carton/pallet |
|---|---|
| Units per carton | 1 |
| Carton weight | NW 25 kg / GW 26 kg |
| Carton size | 46 × 46 × 12 cm |
| CBM per carton | 0.02539 |
| Container loading | 20 ft: 20,650 kg · 40 ft: 25,000 kg · 40 ft HQ: 25,000 kg |
Container figures are planning estimates, not a guaranteed load. They are calculated as the lower of usable packed volume (28 / 56 / 68 m³ for 20 ft, 40 ft and 40 ft HQ) and gross payload (21.5 / 26 / 26 tonnes). Free weights are normally payload-limited, which is why a 40 ft high cube carries no more weight than a standard 40 ft. Actual loading is confirmed against your assortment and destination port before the proforma invoice is issued.
Figures marked in yellow are confirmed per model on the specification sheet supplied with your quotation. Container loading (net/gross weight, carton size, 20ft / 40ft / 40ft HC quantities) is issued with every quote.
Private label options
- Moulded face or printed
- Colour: Black standard; colour-coded on request
- Weight marking in kg, lb or dual
- Bulk export carton, pair box or retail packaging with your artwork
- Sample with your logo before bulk production
Gallery
FAQ
Rubber Tri-Grip Plates: FAQ
What insert do you use?
A machined steel insert, chromed or stainless, is bonded into the bore so the plate does not wear loose on the sleeve.
What is the minimum order quantity?
Standard MOQ is 500 kg per SKU; private-label with a moulded logo starts at 1,000 kg per SKU, as does a custom Pantone colour. Mixed containers across dumbbells, plates, kettlebells, bars and sewn goods are accepted, and a first order is normally one 20ft container.
How long does production take?
Sampling normally takes two to three weeks after artwork approval. Bulk lead time runs 25 to 40 days depending on the line and coating, quoted per order with your proforma invoice.
Do you publish test certificates?
We publish specifications we can stand behind and we do not publish third-party certification we do not hold. Every batch is weight-checked against calibrated scales and inspected in house for coating, dimension and finish. Where a market or a tender requires independent test data, appoint your own testing or inspection agency — we will supply samples and arrange access to production. We would rather you verify than take our word for it.
